LIGHT ENGINE and DISPLAY
DLP® Type and image resolution 1-chip DMD 0.67” UHD - 4K UHD (3840×2160 pixels) – 8.3M pixels
Dynamic Range HDR compliant, with dedicated Display Modes and 4 presets to cover the screen sizes
Lens Super high definition pure-glass lens with telecentric optics
Lens resolution 93 lines per millimeter
Light Source and brightness(1) 450W lamp (dimmable) – up to 6.000 Ansi Lumens
Lamp life expectancy(2) 3000 hours typical in ECO mode
Adjustable iris 10 apertures memorized
SIM2 Perfect Fit and autofocus tracking
Remote Info function SIM2 Customer Care 4
Live Colors Calibration 4.0
Lens Throw ratio (+/-5%) 1.36-2.68:1
Zoom & Focus Motorized with position encoders
Optical Shift +/-75% Vertical, +/- 30% Horizontal
ELECTRONICS AND CONNECTIVITY
Horizontal & vertical scan freq. 15-91kHz/24-120Hz
UHD @ 24/25/30/50/60/70/72/75 Hz
HDTV 480p, 720p 50/60, 1080i 50/60, 1080p 24/50/60 + 576p
PC graphic standard VGA, SVGA, XGA, SXGA, UXGA, WUXGA, UHD, 4K (4096×2160), 10 bit Full Channel Signal Board Video Processing
Color Calibration Live Colors Calibration software 2.0
Digital 2x HDMI (v.1.4a – HDCP 1.4)
1x HDMI (v.2.0a – HDCP 2.2)
1x HDMI audio/video out (v.1.4a – HDCP 1.4)
1x Display Port 1.2
Analog 1x VGA / 3x YCrCb Component
Control 1x USB (A type – FW UpGrade)
1 x RS232 (D-sub 9 pin)
2x IR receivers
1x wired IR receiver
Miscellaneous 2 x 12V 200mA output
Horizontal & Vertical scan freq. 15-91 KHz/24-120 Hz
UHD @ 24/25/30/50/60/70/72/75 Hz
Mains voltage range 100-240 +/-10% (48/62 Hz)
Projector Weight 32 Kg. / 70.5 lbs
Projector dimensions 528 x 215 x 582 mm (20.8” x 8.5” x 22.9”)
Supplied Installation and User Manual
AC power cords
Remote control and batteries
Optional Projector ceiling bracket
Anamorphic lens systems (fixed or motorized)
MER INFORMATION HÄR
- Super High Definition Optics
- New, high-precision telecentric optical path
- DLP technology for a true “Hollywood” lifetime picture quality experience
- 1-chip DMD, 4K UHD Image resolution
- Full HDR features
- 4 HDR presets for 4 screen sizes
- Fully automated SDR-HDR passages
- High Brightness (up to 6000 Ansi Lumens)
- Full color adjustments and Live Color Calibration software (LCC)
- Wide Horizontal and Vertical optical shift
- 2x Super power zoom
- Remote Info function (SIM2 Customer Care 4)
NERO4 UHD – Premium movie experience
Enjoy the clarity and realism of the top of the line of SIM2’s single-chip DLP®-based projectors: UHD (Ultra High Definition) images with the all-new SIM2 NERO 4S UHD HDR projector.
Featuring Texas Instruments’ DLP® 4K UHD chipset, SIM2 NERO 4S UHD HDR delivers exceptional 4K images, high brightness and an accurate, vibrant color palette.
SIM2 has invested heavily in the development of a high-precision telecentric optical system. The SIM2 NERO 4S UHD HDR pure-glass lens provides an unprecedented resolution of 93 line pairs per millimeter to guarantee exceptional on-screen clarity. Special coatings have been applied to the optical components to further enhance image and color performance.
The flexibility of the SIM2 NERO 4S UHD HDR is truly unique: featuring a super power 2x zoom and a super wide lens shift, it suits perfectly almost all large theater applications.
With SIM2 NERO 4S UHD HDR the “widescreen” ratio is easier to achieve than ever thanks to SIM2’s Perfect Fit function. Zoom and focus positioning can be, in fact, stored for 10 different picture formats, from standard 16:9 to 2.40:1 aspect ratio (Letterbox or Anamorphic).
Also, SIM2 NERO 4S UHD HDR is equipped with autofocus tracking for an always perfect focus in any specific installation condition, as well as a remote Info function that provides continuous information on all internal functions.
To aid calibration, the SIM2 NERO 4S UHD HDR features SIM2’s advanced Live Colors Calibration 4.0 software that allows professional calibration of all projection parameters such as complete adjustment of the primary, secondary and white point color coordinates.
SIM2 NERO 4S UHD HDR is not only HDR-capable (accepting an HDR-encoded signal via HDMI 2.0a, HDCP 2.2) but presents a full set of features dedicated to HDR picture display. It offers automatic metadata recognition and an advanced calibration mode, with 4 presets to automatically fit different screen sizes.
SIM2 NERO 4S UHD HDR features a typically stylish ‘made-in-Italy’ design: a distinctive, contemporary cabinet enriched by a luxurious crystal finish by designer Giorgio Revoldini. Available in
